Collection: Metric Disc Magnets

Disc Magnets in Every Size

Our full range of N52 neodymium disc magnets, axially magnetized so the pull comes straight off the flat face. This is the place to start if you know you want a disc but are still choosing a size.

Browse by diameter to find the exact fit for your project. Smaller discs suit infantry and delicate joins; larger discs handle vehicles, terrain, and heavier holds. Each size has its own collection with exact thickness, pull force, and pack options.

Not sure which diameter you need? Our base and magnetization sizing guides walk through the common pairings.

(Diameter/Width down the side, Height across the top)

(Diameter x Height +/-0.1mm)

	0.5 mm	1.0 mm	1.5 mm	2.0 mm	2.5 mm	3.0 mm	3.5 mm	4.0 mm	5.0+ mm
1.0 mm	1.0x0.5 mm 0.02 lbs	1.0x1.0 mm 0.06 lbs	1.0x1.5 mm 0.1 lbs
1.5 mm	1.5x0.5 mm 0.03 lbs	1.5x1.0 mm 0.1 lbs	1.5x1.5 mm 0.11 lbs
2.0 mm	2.0x0.5 mm 0.05 lbs	2.0x1.0 mm 0.14 lbs	2.0x1.5 mm 0.21 lbs	2.0x2.0 mm 0.26 lbs		2.0x3.0 mm 0.31 lbs
2.5 mm	2.5x0.5 mm 0.07 lbs	2.5x1.0 mm 0.22 lbs		2.5x2.0 mm 0.41 lbs	2.5x2.5 mm 0.47 lbs	2.5x3.0 mm 0.51 lbs
3.0 mm	3.0x0.5 mm 0.1 lbs	3.0x1.0 mm 0.29 lbs	3.0x1.5 mm 0.46 lbs	3.0x2.0 mm 0.57 lbs		3.0x3.0 mm 0.72 lbs	3.0x11.5 mm	3.0x4.0 mm 0.79 lbs	3.0x6.0 mm
4.0 mm	4.0x0.5 mm 0.19 lbs	4.0x1.0 mm 0.43 lbs	4.0x1.5 mm 0.68 lbs	4.0x2.0 mm 0.91 lbs	4.0x2.5 mm 1.10 lbs	4.0x3.0 mm 1.20 lbs	4.0x3.5 mm	4.0x4.0 mm 1.42 lbs	4.0x5.0 mm 1.60 lbs
5.0 mm	5.0x0.5 mm 0.25 lbs	5.0x1.0 mm 0.58 lbs	5.0x1.5 mm 0.91 lbs	5.0x2.0 mm 1.24 lbs		5.0x3.0 mm 1.73 lbs		5.0x4.0 mm 2.11 lbs	5.0x5.0 mm 2.43 lbs
6.0 mm		6.0x1.0 mm 0.77 lbs	6.0x1.5 mm 1.22 lbs	6.0x2.0 mm 1.57 lbs	6.0x2.5 mm 1.92 lbs	6.0x3.0 mm 2.35 lbs	6.0x3.5 mm
8.0 mm		8.0x1.0 mm 1.13 lbs		8.0x2.0 mm 2.34 lbs		8.0x3.0 mm 3.74 lbs	8.0x3.5 mm 4.30 lbs
10 mm		10.0x1.0 mm 1.49 lbs		10.0x2.0 mm 3.14 lbs		10.0x3.0 mm 5.16 lbs			10.0x10.0 mm
12 mm		12.0x1.0 mm 1.85 lbs		12.0x2.0 mm 4.03 lbs		12.0x3.0 mm 6.57 lbs
14 mm				14.0x2.0 mm 4.94 lbs		14.0x3.0 mm 7.89 lbs
16 mm				16.0x2.0 mm 5.85 lbs		16.0x3.0 mm
18 mm				18.0x2.0 mm 6.71 lbs		18.0x3.0 mm 10.30 lbs
20 mm				20.0x2.0 mm 7.39 lbs		20.0x3.0 mm 11.37 lbs
25 mm				25.0x2.0 mm 9.72 lbs		25.0x3.0 mm 14.05 lbs
